Horizontal Continuous Band Sealer

SKU: BS-H900

Pricing on request

Configuration, throughput and installation vary — tell us about your line and we'll send a tailored quote.

Available to order

Table-top band sealer for stand-up and flat pouches, with embossed date coder and take-away conveyor.

Request a Quote Talk to an Engineer

Key Features

Continuous PTFE belts — no pouch-size change parts
Digital temperature control for both jaws
Solid / embossed hot-code wheel (3 lines)
Adjustable belt height and speed
Table-top; support conveyor and stand optional

Specifications

CoderEmbossing wheel, 3 lines

Power0.9 kW, 1-phase 230 V

Film TypesPE, PP, laminate, foil (up to ~12 mm total)

Seal Speed0–12 m/min

Seal Width8–12 mm

OrientationHorizontal

TemperatureAmbient–300 °C

Overview

A continuous band sealer that grips the pouch mouth between moving belts, carries it through heating and cooling zones and delivers a strong, uniform seal at up to 12 m/min. An embossing wheel prints a dry batch / date code in the seal; an optional support conveyor keeps filled pouches level. The standard finishing sealer for spice, snack, tea, hardware and chemical pouches.

Related Equipment

Band Sealers & Pouch Sealing Machines

Vertical Continuous Band Sealer
